Compactfilter E10 High temp.
Number: CO 10-66HT
Customer Service
Mai Kaas-Hansen
Effective filtration at high temperature
| Number | CO 10-66HT |
| Name | Compactfilter E10 High temp. |
| Classification list |
|
Add to cart and request a quote to get a price.
SPACER
Your are not logged in
You have to log in to see our prices and to make purchases in the webshop.
High efficiency in higher temperature areas
Robust filter suitable for several different operational conditions
Compact solution with a large filtering surface
Ideal for general ventilation and for use in clean rooms
Specifications
| Applications | Comfort ventilation , Industrial and process ventilation , Cleanrooms , High temperature |
| Width | 592 mm |
| Height | 592 mm |
| Depth | 292 mm |
| Filterklasse | EN 1822 + ISO 29463: EPA E10 |
| Filter media | Fiberglass |
| Filter frame | Plastic |
| AirFlow [m³/t] | 3400 |
| Initial pressure drop [Pa] | 170 |
| Final pressure drop recommended | 600 |
| Operating temperature max. [C°] | 120 |
| Relative humidity [%] | 100 |
| Gasket material | Poleurethane |
